Circular vibrating screen

Feed size: 0 ~ 300 mm

Capacity: 0 ~ 400 t/h

Screen size: 1200×3000 ~ 3600×9000 mm

Power: 3 ~ 74 kW (max single unit 37×2 kW)

You can also send us a message and we will reply to you within 24 hours.

Email: gemma@jiematrading.com Get Latest Price

Product Details

Parameters

Product Details

The YK series eccentric block vibrating screen is a high-efficiency screening device and a replacement for the YA type shaft eccentric circular vibrating screen. This series of screens adopts advanced block eccentric vibration technology, featuring reliable structure, strong vibration force, high screening efficiency, low noise, and convenient maintenance

Product Features

This series of vibrating screens is available in one, two, three, and four-layer structures.

The frequency, amplitude, and screen surface inclination angle are all adjustable.

The vibrating screen adopts a block-eccentric external vibrator structure.

During the serialization process, this vibrating screen fully considered the requirements for the commonality, standardization, and serialization of various components, and adopted the technical design of common vibrating screens in the same industry.

Parameters

Model	Feed size（mm）	Capacity （t/h）	Screen size（mm）	Single layer size（m²）	Power （kw）	Dimension （mm）
2YK1230	0-200	0-80	1200X3000	3.6	3	3200X2400X2400
3YK1230	0-200	0-80	1200X3000	3.6	5.5	3200X2400X2700
2YK1548	0-200	0-160	1500X4800	7.2	11	5000X2900X2900
3YK1548	0-200	0-160	1500X4800	7.2	15	5000X2900X3400
2YK1848	0-200	0-200	1800X4800	8.64	11	5000X3400X3000
3YK1848	0-300	0-200	1800X4800	8.64	15	5000X3400X3500
2YK1860	0-200	0-200	1800X6000	10.8	15	6200X3400X3500
3YK1860	0-300	0-200	1800X6000	10.8	22	6200X3400X4100
2YK2160	0-200	0-250	2100X6000	12.6	22	6200X3700X3500
3YK2160	0-300	0-250	2100X6000	12.6	22	6200X3700X4100
2YK2460	0-200	0-300	2400X6000	14.4	22X2	6200X4100X3800
3YK2460	0-300	0-300	2400X6000	14.4	30X2	6200X4100X4400
2YK2472	0-200	0-300	2400X7200	16.8	22X2	7400X4000X4000
3YK2472	0-300	0-300	2400X7200	16.8	30X2	7400X4100X4600
2YK3072	0-200	0-300	3000X7200	21.6	30X2	7400X4700X4100
3YK3072	0-300	0-300	3000X7200	21.6	30X2	7400X4700X4700
2YK3672	0-200	0-350	3600X7200	25.92	30X2	7400X5400X4100
3YK3672	0-300	0-350	3600X7200	25.92	37X2	7400X5400X4700
2YK3690	0-200	0-400	3600X9000	32.4	37X2	9200X5400X4600
3YK3690	0-300	0-400	3600X9000	32.4	37X2	9200X5400X5200

Notice: There is a chance that JIEMA may make changes on above-mentioned information. Product pictures and parameters about models, data, performances and specifications on this website are for reference only.
